Carbon Black PE Conductive Masterbatch Used For Blowing Conductive PE Film
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | SUGO ESD PLASTICS |
| Certification: | ISO9001:2015; ISO14001:2015; ISO45001:2018 |
| Model Number: | L2149-CM |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1000 Kgs |
|---|---|
| Price: | USD/KG |
| Packaging Details: | 25Kg/Bag, 40 Bags/Pallet, Wrapped arround with shrinkage film |
| Delivery Time: | 5-8 days |
| Payment Terms: | L/C, D/A, T/T |
| Supply Ability: | 1100tons monthly |
|
Detail Information |
|||
| Features: | Super Conductivity And Good Dispersion | Surface Resistivity: | 20-50 Ohms/sq |
|---|---|---|---|
| Carrier Resin: | PE | Valid Time: | Permanent |
| Shape: | Small Particles | Tensile Strength: | 16-20 Mpa |
| Applications: | Blowing Film For PE Bags Or PE Isolation Film | Compatibility: | Good With PE |
| Carbon Black Content: | 40 -50% | Dosage: | 40-60% |
Product Description
Carbon Black PE Conductive Masterbatch Used For Blowing Conductive PE Film
Product Overview:
Our PE Carbon Black Conductive Masterbatch is a high-performance additive engineered to impart superior electrical conductivity to polyethylene (PE) films while maintaining the material’s inherent mechanical properties. Ideal for applications requiring static dissipation, EMI shielding, or antistatic protection, this product combines advanced carbon black dispersion technology with optimized polymer compatibility to ensure consistent performance across a wide range of processing conditions.
Key Physical & Performance Characteristics:
- Conductivity: Utilizes high-purity carbon black with a tailored particle size distribution for efficient electron pathway formation.
- Dispersibility: Excellent compatibility with PE resins, ensuring uniform particle distribution without agglomeration or surface defects.
- Thermal Stability: Maintains conductivity integrity at temperatures up to 200°C, suitable for extrusion, blown film, and injection molding processes.
- Mechanical Integrity: Preserves the tensile strength, flexibility, and impact resistance of the base PE matrix.
- Color Stability: Minimal color shift in final products, with deep black saturation for aesthetic applications.
- Regulatory Compliance: Meets RoHS, REACH standards (when applicable).
Typical Applications:
- Antistatic Packaging: ESD-safe films for electronics, pharmaceuticals, and explosives.
- EMI Shielding: Enclosures for consumer electronics, automotive components, and industrial equipment.
- Industrial Films: Conveyor belts, agricultural covers, and chemical-resistant liners.
- Automotive Interiors: Dashboard components, fuel tank liners, and conductive gaskets.
- Textile Coatings: Static-free carpets, upholstery, and synthetic leather.
Surface Resistivity Performance (Ω/sq):
The conductivity level can be precisely tuned by adjusting the masterbatch addition ratio:
| Dosage | ESD value of Film | Effective |
| 50% | 10^6~9 ohms/sq | Dissipative |
| 55-60% | 10^3~5 ohms/sq | Conductive |
- Note: Actual values may vary based on film thickness, processing equipment, and resin type. Testing is recommended for specific use cases.
Why Choose Our CB-PE Series?
- Cost-Efficiency: Achieves target conductivity with lower loading levels compared to conventional carbon black products.
- Processability: Smooth extrusion without die buildup or melt fracture.
- Customization: Available in pellet sizes tailored for blown film (2-4mm) or injection molding (3-5mm).
- Sustainability: Reduces material waste and energy consumption through optimized dispersion.
Conclusion:
Our PE Carbon Black Conductive Masterbatch offers a versatile, reliable, and cost-effective solution for manufacturers seeking to integrate conductivity into PE films without compromising on performance or aesthetics. With rigorous quality control and a global supply network, we ensure consistent delivery of products that meet the exacting demands of modern industries.
