Anti Static Flame Retardant HDPE Conductive Masterbatch
Product Details:
| Place of Origin: | Dongguan, China |
| Brand Name: | Sugo |
| Certification: | ISO 9001:2015 |
| Model Number: | Conductive |
Payment & Shipping Terms:
| Minimum Order Quantity: | 200 kgs |
|---|---|
| Price: | USD per Kg |
| Packaging Details: | 25kg/bag, in a kraft anti-water paper bag |
| Delivery Time: | 3-7 days |
| Payment Terms: | 100% T/T before shipment, or LC at sight |
| Supply Ability: | 800,000 kgs monthly |
|
Detail Information |
|||
| Brand: | Sugo | Applications: | Electric Conductivity Pipe |
|---|---|---|---|
| Carrier: | HDPE | Color: | Black |
| Surface Resistance: | 10E5 | Capacity: | 800,000 Kgs Monthly |
| Conductive Additive Content: | 20-30% | ASH: | 20-30% |
| MFI: | 2-50 G/10 Min | Advantage: | Conductive And Retardant |
| High Light: | HDPE Conductive Masterbatch,Anti Static Conductive Masterbatch,static resistant materials |
||
Product Description
Flame Retardant & Conductive Master Batch
Description & Technology
Conductive HDPE FR MB taking HDPE as carrier resin, high efficient flame retardant agent and imported
super conductive carbon black as main functional agent compound with dispersion agent manufactured
by imported internal mixer equipment. ‘SUGO’ MB is a kind of upstream product in Flame Retardant &
Electric conductivity Pipe material which makes anti static property below 10E6Ω while flame retardant
property up to V-0 grade. Compare to Brominates Flame Retardant agent, ‘SUGO’ MB melt well with
other resin which making product surface smooth and glossing, easier to process.
Product Features
• High conductive effect, added 100% can meet the static resistance below 10E6Ω
• Static resistant permanent
• Self extinguished off flame
• Applied to HDPE injection molding and extrusion technology
Application
• Applied to HDPE mash gas pipe, vent pipe, white washing, water giving and drain pipe, etc. Not only
suitable for PE FRAS pipe, but also for enhanced FRAS pipe by steel wire wrapping.
• Recommended dosage 100%
| Technical Data | ||
| Test Environment | Lab Temperature: 21 ℃ | |
| Relative Humidity: 58% | ||
| Test Item | Standard | Test Result |
| Appearance | uniform in size and color, surface smooth, none two or more granules joint | Black pellet |
| Melt Index | g/10 min | 24.1g/10 min |
| (190℃, 21.6kg) | ||
| Density | g/cm3 | 1.06g/cm3 |
| Static Resistance | ≤2.5 * 106Ω | 2.5 * 105Ω |
| Flame Retardant | V0 | V0 |
| Moisture | ≤0.1 % | 0.08% |
| Flame Retardant Test Standard & Result | |||
| Item | GB/T 2408-1996 | GB/T 2408-1996 | MT 181 |
| Measurement | Tested stick’s thickness : 6 mm, length: 14 mm | ||
| Burning time | 30 seconds burning on alcohol lamp | 10 seconds burning on alcohol lamp, two times | 30 seconds burning on alcohol lamp |
| Result | self extinguished immediately after off flame | self extinguished immediately after off flame | self extinguished immediately after off flame |
