Carbon Black Super Conductive PP Concentrate or Masterbatch Pellets Used for ESD Corrugated Sheet Extrusion
Product Details:
| Place of Origin: | China |
| Brand Name: | SUGO ESD PLASTICS |
| Certification: | ISO9001:2015; ISO14001:2018; ISO45001:2018 |
| Model Number: | TH2140-ZK |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1000 kgs |
|---|---|
| Price: | USD/KG |
| Packaging Details: | 25Kg/Alu Foil Bag vacuum package, 40 Bags/Pallet, Wrapped arround with shrinkage film |
| Delivery Time: | 5-8 days |
| Payment Terms: | L/C, D/A, T/T |
| Supply Ability: | 1100tons monthly |
|
Detail Information |
|||
| Carrier: | Polypropylene | Conductive Addititve: | Carbon Black |
|---|---|---|---|
| ESD Value Before Delution: | 30-50 Ohms/sq | Dosage 1: | 55-60% Gives 10^3~5 Ohms/sq |
| Dosage 2: | 50% Gives 10^6~9 Ohms/sq | Application: | Antistatic And Conductive PP Corrugated Sheet Or Flute Sheet |
| Pre-Dry: | No Need | Procesing Temperature: | 170-200°C |
| Compliance: | RoHS, Reach | Hazardous Substances: | Free |
| Package: | Alum Foil With Vacuum Package | HS Code: | 3902100099 |
| Grade: | Extrusion | Main Market: | Europe, SouthEast Asia, South America |
Product Description
Product Name:
Factory price Conductive Carbon Black PP Concentrate Pellets used for Conductive and Antistatic PP Corrugated or Flute Sheet
**Product Description**:
** Key Features of Conductive PP Concentrate**
** Application Fields and Market Prospects of PP Conductive Concentrate**
- Application Fields
1. Electronics and Electrical Appliances
- Corrugated PP Sheet, Flute PP Sheet
- In the production of packaging materials for electronic components like anti - static turnover boxes for integrated circuits and wafers, PP conductive masterbatch plays a crucial role. Static electricity can easily damage sensitive electronic components, and the use of materials containing this masterbatch can effectively prevent such damage.
2. Outer casings of electrical appliances
-By adding PP conductive masterbatch, the static electricity generated during the operation of electrical appliances can be released, improving the safety and stability of their use.
3. Automotive Industry
- In the automotive interior, components such as instrument panels and interior parts can be made with materials containing PP conductive masterbatch. This not only endows them with anti - static properties but also enhances their aesthetics and durability.
- In the battery systems of cars, it is used to make battery boxes and battery connection wires, guaranteeing the safe operation and conductive performance of the battery.
** Dosage & Conductivity Guide of Conductive PP Master Batch**
| Dosage of product | range of surface resistivity |
| 45-50% | 10^6 ~ 10^9 ohms/sq |
| 55-60% | 10^3 ~ 10^5 ohms/sq |
Laboratory Devices:
**Notes**:
- Higher carbon black content provides stronger conductivity (lower resistivity).
- Customizable conductivity levels based on client requirements.
**Pre-Dry conditions**
- - 90°C by 4-5 hours
**Procesing temperature**
- -170-200°C
**Advantages**
**Packaging & Storage**
** Market Prospects**
